Rolled Section

The range of structural steel offered by the company caters the demand of the engineering sector and has wide acceptance in power, telecom, precision engineering and other allied industries .The section are rolled from high quality billets having low carbon and high bendable, ductile and easily weldable. We roll cross sections including Fish Plate sections, Liner sections, Sleeper sections, Z bars, bridge expansion joint sections and various unconventional sections according to the specifications and drawings of our clients.
Z Bars IMG-1

Light Rails

Our rolling mills produce light rail which is basically used in Power, Engineering & mining sector .Standard rail lengths are furnished from 8 to 12 meters. Other lengths are available upon request. Steel grades are produced to various qualities and specifications as required by clients.

We also rolled

Round: 10 mm to 200 mm diameter

Flat: 20 x 5 mm to 500 x 32 mm

Square Bar: Up to 125 mm

Light Rail IMG-2
Nominal Weight per Yard Dimensions (in Inches)
HT BW HW W HD FD BD E
30lb 3-1/8 3-1/8 1-11/16 21/64 7/8 1-23/32 17/32 1-25/64
40lb 3-1/2 3-1/2 1-7/8 25/64 1-1/64 1-55/64 5/8 1-9/16
60lb 4-1/4 4-1/4 2-3/8 31/64 1-7/32 2-17/64 49/64 1-115/128
90lb 5-3/8 5-3/8 2-5/8 9/16 1-35/64 2-55/64 59/64 2-45/128
105lb 5-3/16 5-3/16 2-9/16 5/16 1-25/32 2-13/32 1 2-13/64
Light Rails IMG-01
Light Rails IMG-01

Equal Angle

Equal Thickness (mm)
50 X 50 X 5 6
65 X 65 X 5 6 8 10
75 X 75 X 5 6 8 10
90 X 90 X 6 8 10
100 X 100 X 6 8 10 12
110 X 110 X 6 8 10 12
130 X 130 X 8 10 12 16
150 X 150 X 10 12 16 20
200 X 200 X 10 12 16 20

Channel

Width Height
75 mm X 40 mm
100 mm X 50 mm
125 mm X 65 mm
150 mm X 75 mm
175 mm X 75 mm
200 mm X 75 mm
250 mm X 82 mm
300 mm X 90 mm
400 mm X 100 mm

I Beam (IS, IPE standard)

Height Width
125 mm X 75 mm
150 mm X 75 mm
175 mm X 85 mm
200 mm X 100 mm
250 mm X 125 mm
300 mm X 140 mm
350 mm X 140 mm
400 mm X 140 mm
450 mm X 150 mm

H Beam (IS,HEB standard)

Height Width
100 mm X 100 mm
120 mm X 120 mm
140 mm X 140 mm
150 mm X 150 mm
160 mm X 160 mm
180 mm X 180 mm
200 mm X 200 mm
220 mm X 220 mm

RSJ POLE

Height Width
116 mm X 100 mm
125 mm X 70 mm
152 mm X 152 mm
175 mm X 85 mm
203 mm X 152 mm

Specification of steel

Structural Steel

IS 2062 -:-2009 Gr A/ B/ C (including Copper Bearing Quality) IS 10748 Gr I, II & III
BS 4360 -:-1990 Gr 43 A/ B/ C ASTM – A – 36
DIN 17 100 -: -1980 Gr St 37-2/ RSt 37-2, St 44-2, St 44-3
EN 10 025 -: -1993 Gr S 275 JR/ JO and
other equivalent grades

High Tensile Steel

IS 8500:-1991 Gr Fe 490/ 490 B, Fe 540/ 540 B
(including Copper Bearing Quality) Equv SAILMA 350/ 350 Hi/ 410/ 410 Hi IS 961 Gr Fe 540 W-HT
DIN 17 100 -:-1980 Gr St 52-3
DIN 17 102-:-1983 STE 255, STE 285, STE 315, STE 355, STE 380, STE 420
(Including Micro-alloyed High Tensile Grades)
EN 10025 :-1993 Gr S355 JR/ JO/ J2G3/ J2G4/ K2G3 & K2G4
BS 4360 :-1990 Gr 50 A/ B/ C/ D/ E ASTM – A – 572 Gr 50/ 60 and
other equivalent grades

Sectional weight Tolerance

The product are rolled strictly in accordance to IS 808-1989

Weld ability

Sections are rolled from fully killed M.S. Billets. The carbon equivalent in the
material is as low as 0-2% ensuring high weld ability of the product.

Strength

Sections rolled are of high strength from 410 MPA to 600 MPA owing to high manganese content.



Length:

Materials are supplied as per length required by the customers (2500 mm –
13000 mm).8mm to 12mm rounds are supplied as per customer’s requirement in
straight lengths or in coil forms.

Packaging/Bundling

Each bundle is strapped with metallic strips and tags for identification. Bars/rounds/Tor in straight length can be supplied in bundles as per the customer’s requirement and strapped with metallic strips and tags for identification in straight length or “U” bends to facilitate loading and transportation.

Non-Standard Sections

In addition to our standard range of sections we specialize in producing tailor
made hot rolled sections for countless applications that can eliminate time, labour, and expensive machining costs.

Alloy steel & low alloy steel

Requirement we manufacture our products out of various alloy steel and low
alloy steel combinations. Spring steel etc. as per customers

Advantage in a glance:

a) Precision quality.
b) Efficiency in fabrication.
c) Time saving in fabrication.
d) Reduced steel consumption.
e) Resistant to high temperature
